    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine

    Ask Lasest Price
    Brand Name : MOOGE
    Model Number : MT
    Certification : CE
    Price : USD125000
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 1 SET 45Days
    Delivery Time : 45-65days
    • Product Details
    • Company Profile

    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine

    Product Overview
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine
    The PET recycling machine line is mainly used to recycling the waste PET bottles, water bottles,cola bottles, PET sheet and PET packing containers.
    The Recycled waste cola bottle PET recycling machine can easily remove the labels, caps, rings, glue, dirties and other impurities, finally you will get ideal PET flakes.
    Product Parameters
    We have 500-5000 kg/h MT-Series Plastic Double Shaft Shredder PET Washing Line Metal Crusher Machine .
    Model
    Capacity
    Installed Power
    Steam Use
    Water Supply
    Manpower
    Area Required
    MT-500
    500 kg/hr
    190 KW
    Optional
    4-5 m3/hr
    4-6 Person
    60*5*5 m
    MT-1000
    1000 kg/hr
    260 KW
    Optional
    5-7 m3/hr
    8-10 Person
    80*8*5 m
    MT-2000
    2000 kg/hr
    400 KW
    Suggest Use
    10-15 m3/hr
    10-12 Person
    80*8*5 m
    MT-3000
    3000 kg/hr
    600 KW
    80,000 Kcal
    20-30 m3/hr
    12-16 Person
    100*8*10 m
    MT-4000
    4000 kg/hr
    800 KW
    100,000 Kcal
    30-40 m3/hr
    15-20 Person
    135*10*10 m
    MT-5000
    5000 kg/hr
    1000 KW
    120,000 Kcal
    40-50 m3/hr
    15-20 Person
    135*10*10 m
    Product Description

    Label Remover Machine
    Function:remove the labels from the bottle and separate label out from bottles
    Blade made by alloyed steel for long time use
    Blade is fixed by screw on the rotor easy to adjustable and changeable
    The barrel designed with doors opening on it very easy to opening and maintenance
    The machine bottom with holes to drain out liquid which contained in the bottles, good for machine use
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine

    Crusher Machine
    Function: crushing the bottles to PET flakes,with water inlet do wet crushing Chamber opened by screw motor.
    Specially designed PET bottle Crusher Machine can easily get high output and with water doing wet griding can extension the blades use life, reduce the dust generation.
    Bearing house is outside of the crusher chamber so no dirty goes inside for longer use.
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine

    Hot Washing Tank
    Function: with hot water washing to remove oil/glue and other dirty from the flakes
    The tank made with insulation layer to save energy.Feeding caustic soda/detergent to washing
    Its better Heating by steam, can buy a steam boiler to produce the steam, the boiler can heating up by gas/diesel/petrol/LPG
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine
    Horizontal Dewatering Machine
    With high raotary speed reach up to 1500rpm with better effect for removing the water
    With the famous SKF roller bearing fixed outside for long lifespan
    Inside with mesh layer made by SUS304, which is also cleaned by the water spray system
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine

    Final “Zig-zag” label separator
    The Fine dust separator machine will remove the final labels from the flakes to guarantee the PVC content.
    Blower with air flow adjustable,With valve to control the air flux of blower.
    Zig zag main chamber one set made by stainless steel,Chamber with plexiglass window to open and check inside
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine
    Our Customers
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine
    Customers from all over the world come to Jiangsu Muge Machinery to have friendly conversations with employees. We hope to establish a long-term trade relationship with our customers.
    Why Choose Us
    Plastic Washing Line PET Recycling Machine Shredder Crushing Machine
    In order to better serve customers, Mooge Machinery has established a complete sales network and after-sales service system. It has set up multiple offices and technical service centers across the country to provide customers with timely and thoughtful after-sales services, and has established long-term and stable cooperative relations with many countries and regions.
